Quantum Scanning Tip Configurator

100 • ↑ Up • Q6 • Single • Any • 0°
Selected: 2700 CHF
Cart: 0 CHF
5 in stock (21 with higher quality)** Approximate value

The Quantum Scanning Tip (QST) is a diamond-based scanning probe for use in scanning probe microscopy (SPM). Configure your custom tip by selecting the parameters required for your experiments, add to cart, and request a quote.

1
Configure your tipSelect diamond cut, probe type, tip orientation, quality level, and any add-ons below.
2
Add to cartReview the price summary and click Add to cart. Repeat for additional configurations.
3
Request a quoteWhen your cart is ready, click Next to submit your contact details. A formal quote will be sent to your email.

Diamond Cut

Probe Type

Select multiple options as needed.

Tip Orientation

Up orientation required for QSMs.

Quality

Higher quality offers improved sensitivity range

Number of NVs

NV Orientation

Theta is the angle between the NV axis and the normal of the PCB (z axis). Phi is the angle between the NV axis and the line perpendicular to the cantilever (x axis).

Tilt Relative to Tuning Fork

5° tilt is recommended for the QSM.

Additional Details

0/500 characters

Quantity

1
Total2700 CHF
Standard shipping included

Selection Details

100 Diamond Crystal Cut

100 Diamond Crystal Cut

The 100 cut provides four equivalent NV orientations, all at an angle of 54.7° from the surface normal. Ideal for quantum sensing applications requiring uniform sensitivity in multiple directions.
